KV2 JK1 - Single Channel Active DI Box

The JK1 features two 1/4" jack inputs with mix or parallel function with a fixed low cut filter and 15dB pad. Phase Shift and Ground Lift switches are also available. The JK1 is ideal for connection of single keyboards, Guitars or instrument amplifier output conditioning or combining two inputs via the mix function.

Specifically designed as a single channel Active stage Direct Injection (DI) box to maintain and preserve the signal integrity between input and the mixer

  • Live performance
  • Fixed installations
  • Portable



Features

  • Line Driver
  • Phantom power supply
  • Two asymmetrical inputs: Jack 1/4"
  • Mix or parallel input modes
  • Low cut switch
  • Low impedance output
  • LINE OUT - phase switch selector
  • GND ground switch selector: Lift/Gnd



Specifications

System Acoustic Performance

  • -1dB Response:                               20Hz to 100kHz
  • Dynamic Range:                             >130dB
  • Total Harmonic Distortion:            <0.002%

Signal Input

  • Input Channels:                          2x 1/4" Jack
  • Input Impedance:                       1MΩ / 5kΩ
  • Max. Input voltage:                    5V / 20V peak

Signal Output

  • Signal Output Channels:                XLR (line)
  • Output Impedance:                         50Ω

Features

  • Gain:                                               0 / -15dB
  • Phase:                                            0° / 180°
  • High Pass Filter:                           OFF, 80, 160Hz
  • Indicators:                                     Power-ON LED
  • Ground Mode:                              GND / Lift

Power Requirements

  • Phantom Power:                          48 to 56V / 8mA

Cabinet

  • Cabinet Material:                         Heavy duty metal

Physical Dimensions

  • Height:                                         40 mm (1.57")
  • Width:                                          80 mm (3.15")
  • Depth:                                         131 mm (5.16")
  • Weight:                                        610 g (1.34lbs)
